Description
Technical parameter
Products Description
Technical parameter
• Microprocessor Control (CPU).
• 7-STAGE AUTOMATIC CHARGING:
• This is a fully automatic battery charger with 7 charge stages.
• Automatic charging protects your battery from being overcharged. So you can leave the charger connected to the battery indefinitely.
• 7-stage chargers are suitable for most battery types including Calcium, Gel , AGM, Wet , Lead Acid batteries. They may also help restore drained and sulphated batteries.
• Types of batteries: Most types of lead acid batteries including Calcium, Gel , AGM, Wet , Lead Acid, etc..
• Switchmode technology: Yes
• Polarity protection: Yes
• Output short protection: Yes
• Non battery link protection: Yes
• Over voltage protection: Yes
• Over temperature protection: Yes
• Cooling: Fan
• Input voltage: 100-240V AC, 50-60Hz
• Rated output: 12V 7A
• Minimum start voltage: 8.0V
• Battery range: 6-120Ah
• Thermal protect: 65'C+/-5'C
• Efficiency: App. 85%.
• Compliant standards: CB,CE, IEC60335, EN61000, EN55014
• Dimension (L×W×H): 150×86×63mm
• Weight: 415g
